Selection Guides

Selection Guides (工业 板对板连接器)

JAE的电路板级互连解决方案通过业界领先的技术和设计实现一流的可靠性和性能,并适用于各种间距、堆叠高度和针数。我们的精密工业板对板解决方案采用坚固耐用的设计,即便在最具挑战性的应用条件下也可实现大电流/高速连接。

Selection Guides (Industiral Robot and Smart Grid)

JAE Connectors line-up for Industiral Robot and Smart Grid

Selection Guides (Automotive Solutions)

JAE connectors line-up for Automotive Solutions

Connectors Profile

Connectors Profile

A BROAD LINE OF JAE's CONNECTORS FOR DIVERSE APPLICATIONS, INCLUDING MOUNT ON P.C.BOARD, INTERFACING BETWEEN UNITS... FIND ITEMS MOST SUITABLE FOR YOUR PROJECT AMONG THE CONNECTORS PRESENTED HERE.

Board-to-Board Connector Products

WR

0.50mm (.020") Contact Spacing, PCB-to-PCB SMT Connectors

IL-WX

KX14/KX15

TX24/TX25

1.27mm (.050") Contact Spacing, PCB-toPCB Connectors

PCB-TO-FPC/FFC

FA5

0.50mm (.020") Contact Spacing, pitch FFC/FPC Connector (Bottom Contact)

FF03

0.50mm (0.020") Contact Spacing, PCB-to-FPC/FFC Connector

PCB-TO-CABLE/FPC

FI-J

0.40mm (0.15") Contact Spacing, PCB-to-Cable/FPC Connector

FI-R

0.50mm (.020") Contact Spacing, Connector PCB-to-Cable
LVDS High Speed Serial Transmission

FI-X

1.00mm (.039") Contact Spacing, Connector for PCB-to-Cable

FI

1.25mm (.049") Contact Spacing, Connector for PCB-to-Cable

PCB-TO-CABLE

LY

2.0mm (.079") Contact Spacing, PCB-to-Cable (Crimp Type) Connectors

KD10/KD20

2.0mm (.079") Contact Spacing, Board-to-Multi Coaxial Connectors

IL-G

2.50mm (.098") Contact Spacing, PCB-to-Cable (Crimp Type) Connectors

PCI EXPRESS MINI CARD

MM60

MM60 Series is a module socket compatible to specifications standardized in the PCI-SIG

SMART/SIM CARD

SF6

2.54mm (.100”) Contact Spacing, Smart Card, Through Hole Connector

SF7

The SF7 connector is a hinge-type connector supporting the GSM 11.11 standard for small IC chip Cards.

SF7 (Slim)

2.54mm (.100") Contact Spacing, Connector for GSM 11.11 Standard Plug In SIM Card

SF9

2.54mm (.100") Contact Spacing, Tray Connector for GSM 11.11 Standard Plug In SIM Card

MICRO SD/TRANSFLASH™

ST1

1.1mm (.043") Contact Spacing, Connector for MicroSD (TransFlashTM) Card

Input/Output Connector Products (Rectanglar)

DD1

0.50mm (.020") Contact Spacing, Connector conforming to USB2.0 Standard

DD2

0.50mm (.020") Contact Spacing, Connector conforming to USB2.0 Standard

RA1

0.50mm (.020") Contact Spacing, EMI Sheilded, PCB-to-Cable Connectors

Input/Output Connector Products (Circular connectors)

JN2

General Purpose Waterproof, Miniature Connectors

JB5

General Purpose Waterproof Circular Connector

JL05

Waterproof, Circular Connectors

JB1

General Purpose Waterproof, Miniature Circular Connectors

SRCN

Low Cost, General Purpose Miniature Circular Connectors

N/MS

General Purpose Waterproof Circular Connectors

Coaxial Connectors

Coaxial Connectors

Coaxial Connectors line-up

Fiber Optic Products

Fiber Optic Products

Fiber Optic Products

FO-FC

LC Front Shell Cleanable Adapters

FO-EX

Separable, Cleanable Fiber Optic Adapters

PCB-TO-CABLE

MX34

1.1mm (.043") Contact Spacing,Compact Automotive Connectors for PCB-to-Cable Applications

IL-AG7

2.50mm (.098") Contact Spacing, 025 Crimp Contacts, PCB-to-Cable

MX17

2.50mm (.098") Contact Spacing, Complete Mating Connector for Air Bags

MX23A

2.50mm (.098") Contact Spacing, Compact Type Low-profiled Waterproof Connector

MX10

040 Contacts, PCB-to-Cable Applications

PCB-TO-CABLE / CABLE-TO-CABLE

IL-AG5

2.50mm (.098") Contact Spacing, 025 Crimp Contacts, PCB-to-Cable/Cable-to-Cable Applications

IL-AG6

2.50mm (.098") Contact Spacing, 025 Crimp Contacts, PCB-to-Cable/Cable-to-Cable Applications

MX25

6.7mm (.264") Contact Spacing, In-vehicle Coaxial Connectors

MX36

2.50mm (.098") Contact Spacing, Complete Waterproof Mating Relay Connector for Air Bags

CABLE-TO-CABLE

IL-AG9

2.50mm (.098") Contact Spacing, Compact Relay Connector for Vehicles

MX19

2.50mm (.098") Contact Spacing, Small Waterproof Relay Connector
